OCTOPODA MIS®
OCTOPODA MIS® Internal Spinale Fixation System
The OCTOPODA MIS® fixation system was developed to enable patient-friendly thoracolumbar fixation with the aid of cannulated pedicle screws and set screws. The wide range of implants and instruments allows the patient to be treated individually and efficiently. Cannulation and fenestration of screws enable safe and stable cement augmentation.
- 5 Screw diameter in up to 10 lengths available
- Easy-to-break screw tabs that leave a clean break and a low tulip profile
- Fenestration of screws allows cement augmentation
- Self-breaking Set-Screw with patented* design to avoid sharp edges
- Dual Core / Double Lead thread to securely anchor the screw in cortical and cancellous bone
- Straight and pre-bended rods available designed with bulleted tip for easier insertion
- 60° conical angulation of polyaxial screws overall
(*) The patent has regional validity. For more information on the scope of application, please contact our sales team
| Feature | Specification |
|---|---|
| Screws | Polyaxial Screws Monoaxial Screws |
| Diameter | 5,0 mm to 7,0 mm |
| Length | 30 mm to 80 mm |
| Tab | 50 mm & 80 mm |
| Design | Low Tulip profile Fenestration for cement augmentation Dual Core / Double Lead thread |
| Angle | High polyaxial degree of freedom 30° in any direction |
